| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LS133PC
NAND GATE, TTL, PDIP16
|
74LS | Bulk | Active | NAND Gate | 13 | - | 4.75V ~ 5.25V | - | - | - |
|
CD74HCT132MTE4
IC GATE NAND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74AHC14PWR-P
PROTOTYPE
|
74AHC | Bulk | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 1.9V ~ 3.35V | 2.2V ~ 3.85V |
|
SN74LS02DR
IC GATE NOR 4CH 2-INP 14SOIC
|
74LS | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
|
CD4081BM
IC GATE AND 4CH 2-INP 14SOIC
|
4000B | Tube | Active | AND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HCT04NG4
IC INVERTER 6CH 1-INP 14DIP
|
74HCT | Tube | Discontinued at | Inverter | 1 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
SN74LS14DR
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74LS | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 0.5V | 1.9V |
|
CD4093BM96
IC GATE NAND 4CH 2-INP 14SOIC
|
4000B | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 3V ~ 18V | 3.4mA, 3.4mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
SN74HCT02NG4
IC GATE NOR 4CH 2-INP 14DIP
|
74HCT | Tube | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
SN74LS86ADR
IC GATE XOR 4CH 2-INP 14SOIC
|
74LS | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74LS00NSRG4
IC GATE NAND 4CH 2-INP 14SOP
|
74LS | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
CD4077BE
IC GATE XNOR 4CH 2-INP 14DIP
|
4000B | Tube | Active | XNOR (Exclusive NOR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
