| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54LS11FK
IC GATE AND 3CH 3-INP 20LCCC
|
54LS | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN7438D
IC GATE NAND OPEN 4CH 2IN 14SOIC
|
7400 | Tube | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 48mA | 0.8V | 2V |
|
SN7414DG4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
7400 | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 800µA, 16mA | 0.6V | 2V |
|
SNJ54HC132J
54HC132 QUADRUPLE POSITIVE-NAND
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74AUP1G04DCKT
IC INVERTER 1CH 1-INP SC70-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74ALVC08NSR
IC GATE AND 4CH 2-INP 14SOP
|
74ALVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUP1G14DBVR
IC INVERTER 1CH 1-INP SOT23-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 0.8V ~ 3.6V | 4mA, 4mA | 0.1V ~ 0.88V | 0.6V ~ 2.29V |
|
SN74LVC86ARGYR
IC GATE XOR 4CH 2-INP 14VQFN
|
74LVC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
5962-8870801DA
SN54F30 8-INPUT POSITIVE-NAND GA
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
DM5432W/883
OR GATE, TTL/H/L SERIES, TTL
|
- | Bulk | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 800µA, 16mA | 0.8V | 2V |
|
|
SN74ALVC04D
IC INVERTER 6CH 1-INP 14SOIC
|
74ALVC | Tube | Active | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUP1G02DRLRG4
IC GATE NOR 1CH 2-INP SOT5
|
74AUP | Bulk | Active | NOR Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
