| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54S08J
IC GATE AND 4CH 2-INP 14CDIP
|
54S | Bulk | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC7002PW
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HC | Tube | Active | NOR Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
CD4025BPWE4
IC GATE NOR 3CH 3-INP 14TSSOP
|
4000B | Bulk | Discontinued at | NOR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN54S08J
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC04N
IC INVERTER 6CH 1-INP 14DIP
|
74HC | Tube | Active | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HCU7204PWRG4
IC INVERTER 2CH 2-INP 8TSSOP
|
74HCU | Tape & Reel (TR) | Obsolete | Inverter | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.1V | 1.7V ~ 4.8V |
|
SN74S30N
NAND GATE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
5962-9682301QDA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54AHCT | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
CD40106BMT
IC INV SCHMITT 6CH 1-IN 14SOIC
|
4000B | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 3V ~ 18V | 3.4mA, 3.4mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
|
SNJ54ALS38BFK
IC GATE NAND 4CH 2-INP 20LCCC
|
54ALS | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 100µA, 12mA | 0.7V | 2V |
|
SN74AHC04NSLE
INVERTER
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
CD74HCT132EE4
PROTOTYPE
|
74HCT | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
