| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD4011UBE
IC GATE NAND 4CH 2-INP 14DIP
|
4000B | Tube | Active | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
CD4077BNSR
IC GATE XNOR 4CH 2-INP 14SOP
|
4000B | Tape & Reel (TR) | Active | XNOR (Exclusive NOR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AHCT02DG4
IC GATE NOR 4CH 2-INP 14SOIC
|
74AHCT | Bulk | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74F86N
SN74F86 Quadruple 2-Input Exclus
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN74ALVC08IDRG4Q1
IC GATE AND 4CH 2-INP 14SOIC
|
Automotive, AEC-Q100, 74ALVC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
CD4030BM
IC GATE XOR 4CH 2-INP 14SOIC
|
4000B | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HCT02PWT
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74S08DRE4
IC GATE AND 4CH 2-INP 14SOIC
|
74S | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74LVU04ADR
IC INVERTER 6CH 1-INP 14SOIC
|
74LVU | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 5.5V | 12mA, 12mA | 0.3V | 1.7V |
|
SN74HCT08ADBLE
IC GATE NOR 2CH 4-INP 14SSOP
|
74HCT | Bulk | Active | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.8V | 2V |
|
CD4075BEG4
IC GATE OR 3CH 3-INP 14DIP
|
4000B | Tube | Discontinued at | OR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD74HCT08MT
IC GATE AND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
