| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD4001BCM
IC GATE NOR 4CH 2-INP 14SOIC
|
4000B | Tube | Obsolete | NOR Gate | 2 | - | 3V ~ 15V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN54LS27J
54LS27 TRIPLE 3-INPUT POSITIVE-N
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC2G04MDCKREP
IC INVERTER 2CH 2-INP SC70-6
|
74LVC | Tape & Reel (TR) | Active | Inverter | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74S15N
AND GATE, S SERIES, 3-INPUT, TTL
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74HCT14DG4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74HCT | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
5962-9680201QCA
SN54AHC14 HEX SCHMITT-TRIGGER IN
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN7401N3
NAND GATE, TTL, PDIP14
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC00APW
IC GATE NAND 4CH 2-INP 14TSSOP
|
74LVC | Tube | Active | NAND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD74HCT14E-NG
PROTOTYPE
|
74HCT | Bulk | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
|
8409101DA
SN54HC14 HEX SCHMITT-TRIGGER INV
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SNJ54AS804BFK
54AS804B HEX 2-INPUT NAND DRIVER
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
CD74HCT132ME4
IC GATE NAND 4CH 2-INP 14-SOIC
|
74HCT | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
