| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
UCC27536DBVT
IC GATE DRVR LOW-SIDE SOT23-5
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | IGBT, N-Channel MOSFET | 10V ~ 32V | 1.2V, 2.2V | 2.5A, 2.5A |
|
UCC27523DSDT
IC GATE DRVR LOW-SIDE 8SON
|
- | Tape & Reel (TR) | Active | Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 4.5V ~ 18V | 1V, 2.3V | 5A, 5A |
|
LM5100CMAX/NOPB
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 1A, 1A |
|
UCD7100PWP
IC GATE DRVR LOW-SIDE 14HTSSOP
|
- | Bulk | Active | Low-Side | Single | 1 | N-Channel MOSFET | 4.25V ~ 15V | 1.16V, 2.08V | 4A, 4A |
|
LM25101CSD/NOPB
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 1A, 1A |
|
TPS2839PWP
IC GATE DRVR HALF-BRIDG 16HTSSOP
|
- | Tube | Discontinued at | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 10V ~ 15V | 1V, 2V | 4A, 4A |
|
UC3705T
IC GATE DRVR LOW-SIDE TO220-5
|
- | Bulk | Obsolete | Low-Side | Single | 1 | N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.2V | 2A, 2A |
|
TPS2812DG4
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Obsolete | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 4V ~ 14V | 1V, 4V | 2A, 2A |
|
TPS2814DG4
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Bulk | Discontinued at | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 4V ~ 14V | 1V, 4V | 2A, 2A |
|
UC3710DW
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Bulk | Active | Low-Side | Single | 1 | IGBT, N-Channel MOSFET | 4.7V ~ 18V | 0.8V, 2V | 6A, 6A |
|
UC3715NG4
IC GATE DRVR LOW-SIDE 8DIP
|
- | Tube | Obsolete | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 7V ~ 20V | 0.8V, 2V | 500mA, 1A |
|
LM5112Q1SD/NOPB
IC GATE DRVR LOW-SIDE 6WSON
|
Automotive, AEC-Q100 | Tape & Reel (TR) | Active | Low-Side | Single | 1 | N-Channel MOSFET | 3.5V ~ 14V | 0.8V, 2.3V | 3A, 7A |
