| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP2C8T144I8
IC FPGA 85 I/O 144TQFP
|
Cyclone® II | Tray | Active | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 144-LQFP | 144-TQFP (20x20) | Not Verified | 8256 |
|
EP2C8F256C7
IC FPGA 182 I/O 256FBGA
|
Cyclone® II | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 8256 |
|
EP4SE530H40I3N
IC FPGA 976 I/O 1517HBGA
|
STRATIX® IV E | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-HBGA (42.5x42.5) | Not Verified | 531200 |
|
EP4SE820H35C4
IC FPGA 744 I/O 1152HBGA
|
STRATIX® IV E | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-HBGA (42.5x42.5) | Not Verified | 813050 |
|
5CGXFC7C6U19I7
IC FPGA 240 I/O 484UBGA
|
Cyclone® V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | -40°C ~ 100°C (TJ) | 484-FBGA | 484-UBGA (19x19) | Not Verified | 149500 |
|
5CGXBC9E7F35C8N
IC FPGA 560 I/O 1152FBGA
|
Cyclone® V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BGA | 1152-FBGA (35x35) | Not Verified | 301000 |
|
EPF10K50SQC208-3N
IC FPGA 147 I/O 208QFP
|
FLEX-10KS® | Bulk | Active | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 70°C (TA) | 208-BFQFP | 208-PQFP (28x28) | Not Verified | - |
|
EPF10K200SRC240-3B
IC FPGA 182 I/O 240RQFP
|
FLEX-10KS® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 70°C (TA) | 240-BFQFP Exposed Pad | 240-RQFP (32x32) | Not Verified | 9984 |
|
EP2A15B724C8
IC FPGA 492 I/O 724BGA
|
APEX II | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 724-BBGA, FCBGA | 724-BGA (35x35) | Not Verified | 16640 |
|
EP20K400CF672C8N
IC FPGA 488 I/O 672FBGA
|
APEX-20KC® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 16640 |
|
EP2A70F1508C8ES
IC FPGA 1060 I/O 1508FBGA
|
APEX II | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 1508-BBGA, FCBGA | 1508-FBGA, FC (40x40) | Not Verified | 67200 |
|
EPF8452ALC84-3
IC FPGA 68 I/O 84PLCC
|
FLEX 8000 | Tube | Obsolete | 4.75V ~ 5.25V | Surface Mount | 0°C ~ 70°C (TA) | 84-LCC (J-Lead) | 84-PLCC (29.31x29.31) | Not Verified | 336 |
