| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP2S60F1020C3
IC FPGA 718 I/O 1020FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 60440 |
|
EP2A70B724C7
IC FPGA 540 I/O 724BGA
|
APEX II | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 724-BBGA, FCBGA | 724-BGA (35x35) | Not Verified | 67200 |
|
EP2S15F484C4TT
IC FPGA 342 I/O 484FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BBGA, FCBGA | 484-FBGA (23x23) | Not Verified | 15600 |
|
5CGXBC9D7F27C8N
IC FPGA 336 I/O 672FBGA
|
Cyclone® V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BGA | 672-FBGA (27x27) | Not Verified | 301000 |
|
EP2S15F672C3
IC FPGA 366 I/O 672FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 15600 |
|
EP2S130F1508I4RB
IC FPGA 1126 I/O 1508FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 1508-BBGA, FCBGA | 1508-FBGA, FC (40x40) | Not Verified | 132540 |
|
|
EP2A25B724C8
IC FPGA 540 I/O 724BGA
|
APEX II | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 724-BBGA, FCBGA | 724-BGA (35x35) | Not Verified | 24320 |
|
EPF10K200SBC600-1X
IC FPGA 470 I/O 600BGA
|
FLEX-10KS® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 70°C (TA) | 600-BGA | 600-BGA (45x45) | Not Verified | 9984 |
|
EP2S60F484C5
IC FPGA 334 I/O 484FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BBGA | 484-FBGA (23x23) | Not Verified | 60440 |
|
EP20K200CQ240C8ES
IC FPGA 168 I/O 240QFP
|
APEX-20KC® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 240-BFQFP | 240-PQFP (32x32) | Not Verified | 8320 |
|
|
EP2A70F1736C7
IC FPGA
|
APEX II | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | - | - | Not Verified | 67200 |
|
EP20K200RC240-3
IC FPGA 174 I/O 240RQFP
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 240-BFQFP Exposed Pad | 240-RQFP (32x32) | Not Verified | 8320 |
