| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SG166HN2F43E2LG
IC FPGA 688 I/O 1760FBGA
|
Stratix® 10 GX | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 1660000 |
|
1SG165HN2F43I2VGAS
IC FPGA 688 I/O 1760FBGA
|
Stratix® 10 GX | Tray | Active | 0.77V ~ 0.97V | Surface Mount | -40°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 1650000 |
|
10AX032E4F27E3SG
IC FPGA 240 I/O 672FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 672-BBGA, FCBGA | 672-FBGA, FC (27x27) | Not Verified | 320000 |
|
10AX027E1F29E1SG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 270000 |
|
10AX022E3F29E2LG
IC FPGA 288 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 220000 |
|
|
10AX032E4F27I3LG
IC FPGA 240 I/O 672FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 672-BBGA, FCBGA | 672-FBGA, FC (27x27) | Not Verified | 320000 |
|
10AX027E2F29E1HG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 270000 |
|
|
10AX048E2F29E2LG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 480000 |
|
10AX066H4F34I3SGES
IC FPGA 492 I/O 1152FCBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 660000 |
|
|
10AX048E2F29E1HG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 480000 |
|
|
10AX057H2F34I1HG
IC FPGA 492 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 570000 |
|
|
10AX048K3F35I2SG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 480000 |
