| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SG280HN3F43E2VG
IC FPGA 688 I/O 1760FBGA
|
Stratix® 10 GX | Tray | Active | 0.77V ~ 0.97V | Surface Mount | 0°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 2800000 |
|
10AX066H4F34I3SG
IC FPGA 492 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 660000 |
|
5SGSMD8N2F45C2L
IC FPGA 840 I/O 1932FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1932-BBGA, FCBGA | 1932-FBGA, FC (45x45) | Not Verified | 695000 |
|
10AX016E3F27E1SG
IC FPGA 240 I/O 672FBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 100°C (TJ) | 672-BBGA, FCBGA | 672-FBGA (27x27) | Not Verified | 160000 |
|
EP3SL110F1152I3G
IC FPGA 744 I/O 1152FBGA
|
* | Tray | Active | - | - | - | - | - | Not Verified | - |
|
HC1S80F1020AT
IC FPGA 782 I/O 1020FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 79040 |
|
5SGSED8K3F40C2LN
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
10AX048E4F29E3SG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 480000 |
|
|
10AX048H4F34I3SG
IC FPGA 492 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 480000 |
|
10CX085YU484I5G
IC FPGA 208 I/O 484UBGA
|
Cyclone® 10 GX | Tray | Active | - | Surface Mount | -40°C ~ 100°C (TJ) | 484-FBGA | 484-UBGA (19x19) | Not Verified | 85000 |
|
|
10AX032E4F29E3SG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 320000 |
|
|
5SGSED6K2F40C2LN
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 583000 |
