| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
10AX022E3F29E1SG
IC FPGA 288 I/O 780FBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 220000 |
|
5SGSMF35LNAA
IC FPGA 1152FBGA
|
Stratix® V GS | Tray | Obsolete | - | Surface Mount | - | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | - |
|
EP1C3T100I7
IC FPGA 65 I/O 100TQFP
|
Cyclone® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | -40°C ~ 100°C (TJ) | 100-TQFP | 100-TQFP (14x14) | Not Verified | 2910 |
|
10AX027E4F27I3SG
IC FPGA 240 I/O 672FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 672-BBGA, FCBGA | 672-FBGA, FC (27x27) | Not Verified | 270000 |
|
5SGSED8K2F40C2N
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
5SGSMD3H2F35I3N
IC FPGA 432 I/O 1152FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 236000 |
|
1SG250HN3F43I3VG
IC FPGA 688 I/O 1760FBGA
|
Stratix® 10 GX | Tray | Active | 0.77V ~ 0.97V | Surface Mount | -40°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 2500000 |
|
EP20K60ETC144-2
IC FPGA 92 I/O 144TQFP
|
APEX-20KE® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 144-LQFP | 144-TQFP (20x20) | Not Verified | 2560 |
|
1SG280HN3F43I3VG
IC FPGA 688 I/O 1760FBGA
|
Stratix® 10 GX | Tray | Active | 0.77V ~ 0.97V | Surface Mount | -40°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 2800000 |
|
EP20K600EBC652-2X
IC FPGA 488 I/O 652BGA
|
APEX-20KE® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 652-BGA | 652-BGA (45x45) | Not Verified | 24320 |
|
EP1C12Q240C6NAA
IC FPGA 173 I/O 240QFP
|
Cyclone® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 240-BFQFP | 240-PQFP (32x32) | Not Verified | 12060 |
|
10AX022E4F29I3SG
IC FPGA 288 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 220000 |
