| Image | Mfr Part # | Series | Package | Product Status | Type | Interface | Clock Rate | Non-Volatile Memory | On-Chip RAM | Voltage - I/O | Voltage - Core |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SM320C6455BGTZSEP
IC DSP FIXED-POINT 697FCBGA
|
TMS320C645x | Tray | Active | Fixed Point | Host Interface, I²C, McBSP, PCI, UTOPIA | 1GHz | ROM (32kB) | 2.1MB | 1.2V,1.25V,1.5V,1.8V,3.3V | 1.20V |
|
TMS320DM355DZCE216
IC DGTL MEDIA SOC 337NFBGA
|
TMS320DM3x, DaVinci™ | Tube | Not For New Designs | Digital Media System-on-Chip (DMSoC) | ASP, I²C, SPI, UART, USB | 216MHz | ROM (8kB) | 56kB | 1.8V, 3.3V | 1.30V |
|
X66AK2H12AAAWA24
IC DSP ARM SOC BGA
|
66AK2Hx KeyStone Multicore | Tray | Discontinued at | DSP+ARM® | EBI/EMI, Ethernet, DMA, I²C, Serial RapidIO, SPI, UART/USART, USB 3.0 | 1.2GHz DSP, 1.4GHz ARM® | ROM (384kB) | 12.75MB | 0.85V, 1.0V, 1.35V, 1.5V, 1.8V, 3.3V | Variable |
|
TMS320VC549GGU-100
IC FIXED POINT DSP 144-BGA
|
TMS320C54x | Tube | Obsolete | Fixed Point | BSP, Host Interface, Serial Port | 100MHz | ROM (32kB) | 64kB | 3.30V | 2.50V |
|
DM368ZCEZ
IC SOC DIGITAL MEDIA 338NFBGA
|
TMS320DM3x, DaVinci™ | Tray | Active | Digital Media System-on-Chip (DMSoC) | EBI/EMI, Ethernet, I²C, McBSP, SPI, UART, USB | 432MHz | ROM (16kB) | 56kB | 1.8V, 3.3V | 1.20V |
|
SM32C6416DGLZ50AEP
IC DSP FIXED-POINT 532-FCBGA
|
TMS320C6414/15/16 | Tray | Obsolete | Fixed Point | Host Interface, McBSP, PCI, UTOPIA | 500MHz | External | 1.03MB | 3.30V | 1.25V |
|
TMS320DM648CUTA8
IC DGTL MEDIA PROCESSOR 529FCBGA
|
TMS320DM64x, DaVinci™ | Tray | Not For New Designs | Fixed Point | Host Interface, I²C, McASP, PCI, SPI, UART | 800MHz | ROM (64kB) | 576kB | 1.8V, 3.3V | 1.20V |
|
|
66AK2H12DAAWA2
66AK2H12DAAWA2
|
66AK2Hx KeyStone Multicore | Tray | Active | DSP+ARM® | EBI/EMI, Ethernet, DMA, I²C, Serial RapidIO, SPI, UART/USART, USB 3.0 | 1.2GHz | ROM (384kB) | 12.75MB | 0.85V, 1.0V, 1.35V, 1.5V, 1.8V, 3.3V | Variable |
|
TMS32C6415EGLZA6E3
IC FIXED POINT DSP 532-FCBGA
|
TMS320C6414/15/16 | Bulk | Active | Fixed Point | Host Interface, McBSP, PCI, UTOPIA | 600MHz | External | 1.03MB | 3.30V | 1.40V |
|
TMS320DM6437ZDU7
IC DGTL MEDIA PROCESSOR 376-BGA
|
TMS320DM643x, DaVinci™ | Tube | Obsolete | Fixed Point | HPI, I²C, McASP, McBSP, PCI, UART, 10/100 Ethernet MAC | 700MHz | ROM (64kB) | 240kB | 1.8V, 3.3V | 1.05V, 1.20V |
|
TMS320DM642GDK720
DIGITAL SIGNAL PROCESSOR, 32-BIT
|
TMS320DM64x, DaVinci™ | Bulk | Active | Fixed Point | Host Interface, I²C, McASP, McBSP, PCI | 720MHz | External | 160kB | 3.30V | 1.40V |
|
TMS320C6671ACYPA25
IC DSP FIX/FLOAT POINT 841FCBGA
|
TMS320C66x | Tube | Active | Fixed/Floating Point | EBI/EMI, Ethernet MAC, PCIe, I²C, SPI, SRIO, UART | 1.25GHz | ROM (128kB) | 4.56MB | 1.0V, 1.5V, 1.8V | 1.00V |
