| Image | Mfr Part # | Series | Package | Product Status | Type | Interface | Clock Rate | Non-Volatile Memory | On-Chip RAM | Voltage - I/O | Voltage - Core |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
66AK2H12BAAW24
IC DSP ARM SOC 1517FCBGA
|
66AK2Hx KeyStone Multicore | Tray | Discontinued at | DSP+ARM® | EBI/EMI, Ethernet, DMA, I²C, Serial RapidIO, SPI, UART/USART, USB 3.0 | 1.2GHz DSP, 1.4GHz ARM® | ROM (384kB) | 12.75MB | 0.85V, 1.0V, 1.35V, 1.5V, 1.8V, 3.3V | Variable |
|
TMS320DM8127BCYE0
IC DGTL MEDIA PROCESSR 684FCBGA
|
DM81x Video SOC, DaVinci™ | Tray | Obsolete | Digital Media System-on-Chip (DMSoC) | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD, SPI, UART, USB | 500MHz DSP, 600MHz ARM® | ROM (48kB) | 832kB | 1.5V, 1.8V, 3.3V | 1.15V |
|
66AK2G12ABY60FS
PROTOTYPE
|
66AK2G1x KeyStone II Multicore | Bulk | Active | DSP+ARM® | CAN, DMA, EBI/EMI, Ethernet, I²C, McASP, McBSP, MMC/SD, QSPI, SPI, UART, USB | 600MHz | External | 1MB | 1.8V, 3.3V | 0.9V |
|
TMS320C6670ACYPA2
IC DSP FIX/FLOAT POINT 841FCBGA
|
TMS320C66x | Tray | Active | Fixed/Floating Point | EBI/EMI, Ethernet MAC, PCIe, I²C, SPI, SRIO, UART | 1.2GHz | ROM (128kB) | 6.25MB | 1.0V, 1.5V, 1.8V | 1.00V |
|
TMS320C6746BZCG4
IC DSP FIX/FLOAT POINT 361NFBGA
|
TMS320C674x | Tray | Discontinued at | Fixed/Floating Point | EBI/EMI, Ethernet MAC, Host Interface, I²C, McASP, McBSP, SPI, UART, USB | 456MHz | ROM (1.088MB) | 488kB | 1.8V, 3.3V | 1.00V, 1.10V, 1.20V, 1.30V |
|
|
DRA780BDGABFRQ1
SOC PROCESSOR W/ 500 MHZ C66X DS
|
DRA78x | Tape & Reel (TR) | Active | Floating Point | - | 500MHz | ROM (16kB) | 512kB | - | - |
|
TMS320C5535AZAYA05
IC DSP FIXED-POINT 144BGA
|
TMS320C55x | Tray | Active | Fixed Point | I²C, I²S, LCD, MMC/SD, SPI, UART, USB | 50MHz | ROM (128kB) | 320kB | 1.8V, 2.5V, 2.75V, 3.3V | 1.05V |
|
TMS320DM8168SCYG
IC DGTL MEDIA PROCESSR 1031FCBGA
|
DM81x Video SOC, DaVinci™ | Tray | Active | Digital Media System-on-Chip (DMSoC) | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | 800MHz DSP, 1.0GHz ARM® | ROM (48kB) | 1.5MB | 1.5V, 1.8V, 3.3V | 1.00V |
|
TMS320C6678CYP25
IC DSP FIX/FLOAT POINT 841FCBGA
|
TMS320C66x | Tube | Discontinued at | Fixed/Floating Point | EBI/EMI, I²C, PCIe, SPI, TSIP, UART, 10/100/1000 Ethernet | 1.25GHz | ROM (128kB) | 8.5MB | 1.0V, 1.5V, 1.8V | 1.00V |
|
TMS320C6657CZHA
IC DSP FIX/FLOAT POINT 625FCBGA
|
TMS320C66x | Tray | Active | Fixed/Floating Point | DDR3, EBI/EMI, Ethernet, McBSP, PCIe, I²C, SPI, UART, UPP | 1GHz | ROM (128kB) | 2.06MB | 1.0V, 1.5V, 1.8V | 1.00V |
|
TMS320DM368ZCED
IC DGTL MEDIA SOC 338NFBGA
|
TMS320DM3x, DaVinci™ | Bulk | Active | Digital Media System-on-Chip (DMSoC) | EBI/EMI, Ethernet, I²C, McBSP, SPI, UART, USB | 432MHz | ROM (16kB) | 56kB | 1.8V, 3.3V | 1.35V |
|
TMS320VC5507ZHH
IC FIXED POINT DSP 179-BGA
|
TMS320C55x | Bulk | Obsolete | Fixed Point | Host Interface, I²C, McBSP | 200MHz | ROM (64kB) | 128kB | 3.00V, 3.30V | 1.60V |
