| Image | Mfr Part # | Series | Package | Product Status | Type | Number of Elements | Output Type | Voltage - Supply, Single/Dual (±) | Voltage - Input Offset (Max) | Current - Input Bias (Max) | Current - Output (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAX941ESA+T
IC COMPARATOR 1 W/LATCH 8SOIC
|
- | Tape & Reel (TR) | Active | with Latch, Shutdown | 1 | CMOS, Push-Pull, TTL | 2.7V ~ 5.5V | 2mV @ 5.5V | 0.15µA @ 5.5V | - |
|
MAX993ESD+
IC COMPARATOR 4 GEN PUR 14SOIC
|
- | Tube | Active | General Purpose | 4 | CMOS, Push-Pull, Rail-to-Rail, TTL | 2.5V ~ 5.5V, ±1.25V ~ 2.75V | 5mV @ 5.5V | 1pA @ 5.5V | - |
|
MAX9043AEUB+
IC COMPARATR 2 W/VOLT REF 10UMAX
|
- | Tube | Active | with Voltage Reference | 2 | CMOS, Push-Pull, Rail-to-Rail, TTL | 2.5V ~ 5.5V | 5mV @ 5V | 1pA @ 5V | 8mA |
|
MAX9109EUT+T
IC COMPARATOR 1 W/LATCH SOT6
|
- | Tape & Reel (TR) | Active | with Latch | 1 | TTL | 4.5V ~ 5.5V | 1.6mV @ 5V | 0.125µA @ 5V | - |
|
MAX9042AESA+T
IC COMPARATOR 2 W/VOLT REF 8SOIC
|
- | Tape & Reel (TR) | Obsolete | with Voltage Reference | 2 | CMOS, Push-Pull, Rail-to-Rail, TTL | 2.5V ~ 5.5V | 5mV @ 5V | 1pA @ 5V | 8mA |
|
MAX9202EUD+
IC COMPARATOR 2 W/LATCH 14TSSOP
|
- | Tube | Active | with Latch | 2 | TTL | 4.75V ~ 10.5V, ±2.375V ~ 5.75V | 4mV @ ±5V | 5µA @ ±5V | - |
|
MAX9108EUD+
IC COMPARATOR 4 GEN PUR 14TSSOP
|
- | Tube | Active | General Purpose | 4 | TTL | 4.5V ~ 5.5V | 1.6mV @ 5V | 0.125µA @ 5V | - |
|
MAX901BESE+
IC COMPARATOR 4 GEN PUR 16SOIC
|
- | Tube | Active | General Purpose | 4 | TTL | 5V ~ 10V, ±2.5V ~ 5V | 4mV @ ±5V | 10µA @ ±5V | - |
|
MAX9077ESA-T
IC COMPARATOR 2 GEN PUR 8SOIC
|
- | Tape & Reel (TR) | Obsolete | General Purpose | 2 | CMOS, Push-Pull, Rail-to-Rail, TTL | 2.1V ~ 5.5V | 1mV @ 5V | 0.005µA @ 5V | - |
|
MAX996ESD
IC COMPARATOR 4 GEN PUR 14SOIC
|
- | Tube | Obsolete | General Purpose | 4 | CMOS, Open-Drain, Rail-to-Rail, TTL | 2.5V ~ 5.5V, ±1.25V ~ 2.75V | 5mV @ 5.5V | 1pA @ 5.5V | - |
|
MAX9201EUE+T
IC COMPARATOR 4 GEN PUR 16TSSOP
|
- | Tape & Reel (TR) | Active | General Purpose | 4 | TTL | 4.75V ~ 10.5V, ±2.375V ~ 5.75V | 4mV @ ±5V | 5µA @ ±5V | - |
|
MAX983EPA+
IC COMPARATOR 2 W/VOLT REF 8DIP
|
- | Tube | Obsolete | with Voltage Reference | 2 | - | 2.5V ~ 11V, ±1.25V ~ 5.5V | 10mV @ 5V | - | - |
