| Image | Mfr Part # | Series | Package | Product Status | Type | Number of Elements | Output Type | Voltage - Supply, Single/Dual (±) | Voltage - Input Offset (Max) | Current - Input Bias (Max) | Current - Output (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAX9017AEKA
IC COMPARATOR 2 W/VOLT REF SOT23
|
Automotive, AEC-Q100, Beyond-the-Rails™ | Bulk | Active | with Voltage Reference | 2 | Push-Pull, CMOS, Output | 1.8V ~ 5.5V | 5mV @ 5V | 1000pA @ 5V | 35mA |
|
MAX964ESE
IC COMPARATOR 4 GEN PUR 16SOIC
|
Beyond-the-Rails™ | Tube | Obsolete | General Purpose | 4 | CMOS, TTL | 2.7V ~ 5.5V | 1.5mV @ 5V | 15µA @ 5V | - |
|
MAX9015AEKA-T
IC COMPARATOR 1 W/VOLT REF SOT23
|
Beyond-the-Rails™ | Tape & Reel (TR) | Obsolete | with Voltage Reference | 1 | CMOS, Push-Pull, Rail-to-Rail | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
|
MAX49017ATA/VY+
IC COMPARATOR 2 GEN PUR 8TDFN
|
Automotive, AEC-Q100 | Strip | Active | with Voltage Reference | 2 | Push-Pull | 1.7V ~ 5.5V | 8mV @ 3.3V | 0.005µA @ 3.3V | 100nA (Min) |
|
MAX918EUK+T
IC COMPARATOR 1 W/VOLT REF SOT23
|
Beyond-the-Rails™ | Tape & Reel (TR) | Active | with Voltage Reference | 1 | Open-Drain, Rail-to-Rail | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
|
MAX9026EBT+T
IC COMPARATOR 1 W/VOLT REF 6WLP
|
Beyond-the-Rails™ | Tape & Reel (TR) | Active | with Voltage Reference | 1 | Open-Drain, Rail-to-Rail | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
|
MAX972EBL-T
IC COMPARATOR 2 W/VOLT REF 8UCSP
|
- | Bulk | Active | with Voltage Reference | 2 | Open-Drain | 2.5V ~ 11V, ±1.25V ~ 5.5V | 10mV @ 5V | - | 25µA @ 5V |
|
MAX9019EKA+T
IC COMPARATOR 2 GEN PUR SOT23-8
|
Beyond-the-Rails™ | Tape & Reel (TR) | Active | General Purpose | 2 | CMOS, Push-Pull, Rail-to-Rail | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
|
MAX961ESA-T
IC COMPARATOR 1 GEN PUR 8SOIC
|
Beyond-the-Rails™ | Tape & Reel (TR) | Obsolete | General Purpose | 1 | CMOS, Complementary, TTL | 2.7V ~ 5.5V | 1.5mV @ 5V | 15µA @ 5V | - |
|
MAX997EUA+
IC COMPARATOR 1 GEN PUR 8UMAX
|
Beyond-the-Rails™ | Tube | Active | General Purpose | 1 | CMOS, TTL | 2.7V ~ 5.5V | 1.5mV @ 5V | 15µA @ 5V | - |
|
MAX9015AEKA+T
IC COMPARATOR 1 W/VOLT REF SOT23
|
Beyond-the-Rails™ | Tape & Reel (TR) | Active | with Voltage Reference | 1 | CMOS, Push-Pull, Rail-to-Rail | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
|
MAX919EUK/V+T
IC COMPARATOR 1 GEN PUR SOT23-5
|
Automotive, AEC-Q100 | Tape & Reel (TR) | Active | General Purpose | 1 | CMOS, Push-Pull, Rail-to-Rail, TTL | 1.8V ~ 5.5V | 5mV @ 5V | 0.001µA @ 5V | 50mA |
