| Image | Mfr Part # | Series | Package | Product Status | Type | Number of Elements | Output Type | Voltage - Supply, Single/Dual (±) | Voltage - Input Offset (Max) | Current - Input Bias (Max) | Current - Output (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLC339MDR
IC COMPARATOR 4 GEN PUR 14SOIC
|
LinCMOS™ | Tape & Reel (TR) | Active | General Purpose | 4 | CMOS, Open-Drain | 4V ~ 16V | 5mV @ 10V | 5pA @ 5V | 20mA |
|
TLV3702ID
IC COMPARATOR 2 GEN PUR 8SOIC
|
- | Tube | Active | General Purpose | 2 | CMOS, Push-Pull, Rail-to-Rail | 2.7V ~ 16V, ±1.35V ~ 8V | 5mV @ 15V | 250pA @ 15V | 10mA |
|
LM219J
IC COMPARATOR 2 GEN PUR 14CDIP
|
- | Tube | Obsolete | General Purpose | 2 | DTL, Open-Collector, Open-Emitter, RTL, TTL | 5V ~ 36V, ±2.5V ~ 18V | 4mV @ ±15V | 0.5µA @ ±15V | - |
|
TLC3702IDR
IC COMPARATOR 2 GEN PUR 8SOIC
|
LinCMOS™ | Tape & Reel (TR) | Active | General Purpose | 2 | CMOS, Push-Pull, TTL | 3V ~ 16V | 5mV @ 10V | 5pA @ 5V | 20mA |
|
LM111JGB
DIFFERENTIAL COMPARATOR WITH STR
|
- | Tube | Active | Differential | 1 | Open-Collector, Open-Emitter | 3.5V ~ 30V, ±1.75V ~ 15V | 3mV @ ±15V | 0.1µA @ ±15V | - |
|
LM393D
IC COMPARATOR 2 GEN PUR 8SOIC
|
- | Tube | Active | General Purpose | 2 | CMOS, DTL, ECL, MOS, Open-Collector, TTL | 2V ~ 36V, ±1V ~ 18V | 5mV @ 30V | 0.25µA @ 5V | 18mA @ 5V |
|
LM393AD
IC COMPARATOR 2 DIFF 8SOIC
|
- | Tube | Last Time Buy | Differential | 2 | Open-Collector, Rail-to-Rail | 2V ~ 36V, ±1V ~ 18V | 2mV @ 30V | 0.25µA @ 5V | 20mA |
|
|
8601401HA
HIGH SPEED DUAL COMPARATOR 10-CF
|
- | Tube | Active | General Purpose | 2 | Open-Collector, DTL, RTL, TTL | 36V | 4mV @ ±15V | 0.5µA @ ±15V | - |
|
TLC339IDR
IC COMPARATOR 4 GEN PUR 14SOIC
|
LinCMOS™ | Tape & Reel (TR) | Active | General Purpose | 4 | CMOS, Open-Drain | 3V ~ 16V | 5mV @ 10V | 5pA @ 5V | 20mA |
|
TLC393CDR
IC COMPARATOR 2 GEN PUR 8SOIC
|
LinCMOS™ | Tape & Reel (TR) | Active | General Purpose | 2 | MOS, Open-Drain | 3V ~ 16V | 5mV @ 10V | 5pA @ 5V | 20mA |
|
|
LM193AJRLQMLV
LOW POWER LOW OFFSET VOLTAGE DUA
|
- | Tube | Active | General Purpose | 2 | Open-Collector, Rail-to-Rail | 2V ~ 36V, ±1V ~ 18V | 2mV @ 5V | 1000pA @ 5V | 6mA |
|
LM339ADG4
IC COMPARATOR 4 DIFF 14SOIC
|
- | Tube | Discontinued at | Differential | 4 | Open-Collector, Rail-to-Rail | 2V ~ 30V, ±1V ~ 15V | 3mV @ 30V | 0.25µA @ 5V | 20mA |
