| Image | Mfr Part # | Series | Package | Product Status | Type | Number of Elements | Output Type | Voltage - Supply, Single/Dual (±) | Voltage - Input Offset (Max) | Current - Input Bias (Max) | Current - Output (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM193AJRLQMLV
LOW POWER LOW OFFSET VOLTAGE DUA
|
- | Tube | Active | General Purpose | 2 | Open-Collector, Rail-to-Rail | 2V ~ 36V, ±1V ~ 18V | 2mV @ 5V | 1000pA @ 5V | 6mA |
|
LM339ADG4
IC COMPARATOR 4 DIFF 14SOIC
|
- | Tube | Discontinued at | Differential | 4 | Open-Collector, Rail-to-Rail | 2V ~ 30V, ±1V ~ 15V | 3mV @ 30V | 0.25µA @ 5V | 20mA |
|
|
8601401HA
HIGH SPEED DUAL COMPARATOR 10-CF
|
- | Tube | Active | General Purpose | 2 | Open-Collector, DTL, RTL, TTL | 36V | 4mV @ ±15V | 0.5µA @ ±15V | - |
|
TLC339IDR
IC COMPARATOR 4 GEN PUR 14SOIC
|
LinCMOS™ | Tape & Reel (TR) | Active | General Purpose | 4 | CMOS, Open-Drain | 3V ~ 16V | 5mV @ 10V | 5pA @ 5V | 20mA |
|
|
LM139E/883
LOW POWER LOW OFFSET VOLTAGE QUA
|
- | Bulk | Active | General Purpose | 4 | Open-Collector, Open-Drain, Rail-to-Rail | 5V ~ 30V, ±2.5V ~ 15V | 4mV @ 30V | 0.1µA @ 5V | - |
|
TLV3401CD
IC COMPARATOR 1 GEN PUR 8SOIC
|
- | Bulk | Active | General Purpose | 1 | CMOS, Open-Drain | 2.5V ~ 16V, ±1.25V ~ 8V | 3.6mV @ 15V | 250pA @ 15V | 10mA |
|
|
LM393P-P2
PROTOTYPE
|
- | Bulk | Active | General Purpose | 2 | Open-Collector, Rail-to-Rail | 2V ~ 30V, ±1V ~ 15V | 5mV @ 30V | 0.25µA @ 5V | 6mA @ 5V |
|
TL712CPWE4
IC COMPARATOR 1 DIFF 8TSSOP
|
- | Tube | Obsolete | Differential | 1 | Complementary, Push-Pull, Tri-State, TTL | 4.75V ~ 5.25V | - | - | - |
|
|
LMV7219M5X/S7002242
PROTOTYPE
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
TLV1922DSGR
65V OPEN-DRAIN COMPARATOR WITH 2
|
TLV192x | Tape & Reel (TR) | Active | with Voltage Reference | 2 | Open-Drain | 3.3V ~ 65V | 3mV @ 24V | 0.001µA @ 24V | 1mA @ 24V |
|
|
LM2901QPWRG4HE
PROTOTYPE
|
- | Bulk | Active | Differential | 4 | - | 2V ~ 30V, ±1V ~ 15V | 7mV @ 5V | 0.25µA @ 5V | 16mA |
|
LMV7272TL
IC COMPARATOR 2 GEN PUR 8DSBGA
|
- | Bulk | Active | General Purpose | 2 | Push-Pull, CMOS, Rail-to-Rail | 1.8V ~ 5.5V, ±0.9V ~ 2.75V | 4mV @ 5V | 0.01pA (Typ) | - |
