| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74F08DRE4
IC GATE AND 4CH 2-INP 14SOIC
|
74F | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
5962-86833012A
IC GATE NAND 4CH 2-INP 20LCCC
|
54ALS | Bulk | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SNJ54ALS20AFK
IC GATE NAND 2CH 4-INP 20LCCC
|
54ALS | Tube | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 400µA | 0.8V | 2V |
|
CD74HC4002PWR
IC GATE NOR 2CH 4-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Active | NOR Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC266D
IC GATE XNOR OD 4CH 2-INP 14SOIC
|
74HC | Tube | Discontinued at | XNOR (Exclusive NOR) | 2 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74F21DRG4
IC GATE AND 2CH 4-INP 14SOIC
|
74F | Tape & Reel (TR) | Discontinued at | AND Gate | 4 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
SNJ54ALS11AFK
IC GATE AND 3CH 3-INP 20LCCC
|
54ALS | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
SN74HC02D
IC GATE NOR 4CH 2-INP 14SOIC
|
74HC | Tube | Discontinued at | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74F02DRG4
IC GATE NOR 4CH 2-INP 14SOIC
|
74F | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC00PW
IC GATE NAND 4CH 2-INP 14TSSOP
|
74HC | Tube | Discontinued at | NAND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC32NS
IC GATE OR 4CH 2-INP 14SO
|
74HC | Tube | Discontinued at | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.1V ~ 0.26V | 1.998V ~ 5.8V |
|
|
SN74F86NE4
4-CH, 2-INPUT, 4.5-V TO 5.5-V BI
|
74F | Tube | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
