| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54LS20W
IC GATE NAND 2CH 4-INP 14CFP
|
54LS | Tube | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
74LS55SC
AND-OR-INVERT GATE, TTL, PDSO14
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
SNJ54LS03W
IC GATE NAND 4CH 2-INP 14CFP
|
54LS | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 100µA, 4mA | 0.7V | 2V |
|
CD4069MJ/883
INVERTER, CMOS
|
- | Bulk | Active | Inverter | 1 | - | 3V ~ 15V | 8.8mA, 8.8mA | 1V ~ 3V | 4V ~ 12V |
|
DM54LS27J/883
NOR GATE, LS SERIES TTL
|
- | Bulk | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
7410PCQR
NAND GATE, TTL, PDIP14
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN54LS08J
IC GATE AND 4CH 2-INP 14CDIP
|
54LS | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SNJ54LS09W
IC GATE AND 4CH 2-INP 14CFP
|
54LS | Tube | Active | AND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 100µA, 4mA | 0.7V | 2V |
|
|
JM54AC04BDA-RH
54AC04 - HEX INVERTER - (SMD - J
|
- | Bulk | Active | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
54S10FM
NAND GATE, TTL
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
5430DMQB
NAND GATE
|
- | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
|
5962R8754903VDA
SPACE 4-CH, 2-INPUT, 2-V TO 6-V
|
- | Tube | Active | NAND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
