| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74F30D
IC GATE NAND 1CH 8-INP 14SOIC
|
74F | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC32NSR
IC GATE OR 4CH 2-INP 14SOP
|
74HC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC03PWR
IC GATE NAND OD 4CH 2-IN 14TSSOP
|
74HC | Tape & Reel (TR) | Active | NAND Gate | 2 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74F08DE4
IC GATE AND 4CH 2-INP 14SOIC
|
74F | Bulk | Last Time Buy | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC32N
IC GATE OR 4CH 2-INP 14DIP
|
74HC | Tube | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC86PW
IC GATE XOR 4CH 2-INP 14TSSOP
|
74HC | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC20PWT
IC GATE NAND 2CH 4-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Discontinued at | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC04PWT
IC INVERTER 6CH 1-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC08DT
IC GATE AND 4CH 2-INP 14SOIC
|
74HC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74HC14N
IC INVERT SCHMITT 6CH 1-IN 14DIP
|
74HC | Tube | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SNJ54S10W
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74HC7032D
IC GATE OR SCHMIT 4CH 2IN 14SOIC
|
74HC | Tube | Active | OR Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
