| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
M38510/30501SDA
SPACE 4-CH, 2-INPUT, 4.5-V TO 5.
|
54LS | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
54LS21LM
NAND GATE, LS SERIES, 2 FUNC, 4-
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN74LV132APWR-P
PROTOTYPE
|
74LV | Bulk | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | - | 1.75V ~ 3.5V |
|
|
SNJ54H00WA
NAND GATE, TTL/H/L SERIES, TTL
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74AHC00PWR
IC GATE NAND 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC32DGVR
IC GATE OR 4CH 2-INP 14TVSOP
|
74AHC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC1G09DCKR
IC GATE AND OD 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74LV32ARGYR
IC GATE OR 4CH 2-INP 14VQFN
|
74LV | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
54LS20DMQB
NAND GATE
|
54LS | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SNJ54AC08FK
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54AC | Tube | Active | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74AHC14DRE4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AHC86N
IC GATE XOR 4CH 2-INP 14DIP
|
74AHC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
