| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM5060QDGSRDN
PROTOTYPE
|
Automotive, AEC-Q100 | Bulk | Active | High-Side | Single | 1 | N-Channel MOSFET | 5.5V ~ 65V | 0.8V, 2V | - |
|
LM2104DR
107-V, 0.5-A/0.8-A HALF-BRIDGE G
|
- | - | - | - | - | - | - | - | - | - |
|
|
LM5060Q1MM/S7002430
PROTOTYPE
|
- | Bulk | Active | High-Side | Single | 1 | N-Channel MOSFET | 5.5V ~ 65V | - | - |
|
LM5110-1M
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Obsolete | Low-Side | Independent | 2 | N-Channel MOSFET | 3.5V ~ 14V | 0.8V, 2.2V | 3A, 5A |
|
|
UC1709L883B
1.5-A/1.5-A DUAL-CHANNEL GATE DR
|
- | Tube | Active | Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.4V | 1.5A, 1.5A |
|
|
UCC27321PE4
AUTOMOTIVE 9-A/9-A SINGLE-CHANNE
|
- | Tube | Active | Low-Side | Single | 1 | N-Channel, P-Channel MOSFET | 4V ~ 15V | 1V, 2V | 9A, 9A |
|
|
SN75372PS
PROTOTYPE
|
- | Bulk | Active | Low-Side | Synchronous | 2 | N-Channel MOSFET | - | 0.8V, 2V | 500mA, 500mA |
|
LM5100ASDX
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 3A, 3A |
|
|
LM2103DR
105-V, 0.5-A/0.8-A HALF-BRIDGE G
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 18V | - | 500mA, 800mA |
|
|
SM72482X/NOPB
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Low-Side | Independent | 2 | N-Channel MOSFET | 3.5V ~ 14V | 0.8V, 2.2V | 3A, 5A |
|
|
UCC57108BDR
Low-side 3A/3A driver with desat
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | IGBT, SiC MOSFET | 8.5V ~ 26V | 1.6V, 1.8V | 3A, 3A |
|
|
UCC27325PE4
4-A/4-A DUAL-CHANNEL GATE DRIVER
|
- | Tube | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 15V | 1V, 2V | 4A, 4A |
