| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP3SE260F1152I4L
IC FPGA 744 I/O 1152FBGA
|
Stratix® III E | Tray | Obsolete | 0.86V ~ 1.15V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 255000 |
|
EP3SE260H780C4LN
IC FPGA 488 I/O 780HBGA
|
Stratix® III E | Tray | Obsolete | 0.86V ~ 1.15V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA, FCBGA | 780-HBGA (33x33) | Not Verified | 255000 |
|
EP2S30F484C4
IC FPGA 342 I/O 484FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BBGA | 484-FBGA (23x23) | Not Verified | 33880 |
|
EP2S60F672I5N
IC FPGA 492 I/O 672FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 60440 |
|
EP2S130F1508C5RB
IC FPGA 1126 I/O 1508FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 1508-BBGA, FCBGA | 1508-FBGA, FC (40x40) | Not Verified | 132540 |
|
EP2S60F1020C4N
IC FPGA 718 I/O 1020FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 60440 |
|
EP20K200FC484-1
IC FPGA 382 I/O 484FBGA
|
APEX-20K® | Bulk | Active | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BBGA | 484-FBGA (23x23) | Not Verified | - |
|
EP20K100FC324-3
IC FPGA 252 I/O 324FBGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 324-BGA | 324-FBGA (19x19) | Not Verified | 4160 |
|
EP20K200QC208-2
IC FPGA 144 I/O 208QFP
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 208-BFQFP | 208-PQFP (28x28) | Not Verified | 8320 |
|
|
EP20K100FC144-1X
IC FPGA 93 I/O 144TQFP
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 144-LQFP | 144-TQFP (20x20) | Not Verified | 4160 |
|
EP20K100BC356-2
IC FPGA 252 I/O 356BGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 85°C (TJ) | 356-LBGA | 356-BGA (35x35) | Not Verified | 4160 |
|
HC1S40F780NAF
IC FPGA 613 I/O 780FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 41250 |
