| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
5AGXFB7K4F40C4G
IC FPGA 704 I/O 1517FBGA
|
Arria V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA, FC (40x40) | Not Verified | 504140 |
|
|
5AGXFB1H4F40I5G
IC FPGA 704 I/O 1517FBGA
|
Arria V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA, FC (40x40) | Not Verified | 300000 |
|
EP3SE50F484I3G
IC FPGA 296 I/O 484FBGA
|
Stratix® III E | Tray | Active | 0.86V ~ 1.15V | Surface Mount | -40°C ~ 100°C (TJ) | 484-BBGA, FCBGA | 484-FBGA (23x23) | Not Verified | 47500 |
|
EP3SE110F1152C3
IC FPGA 744 I/O 1152FBGA
|
Stratix® III E | Tray | Obsolete | 0.86V ~ 1.15V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 107500 |
|
EP2S60F672C3
IC FPGA 492 I/O 672FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 60440 |
|
|
5AGXFB5K4F40I3G
IC FPGA 704 I/O 1517FBGA
|
Arria V GX | Tray | Active | 1.12V ~ 1.18V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA, FC (40x40) | Not Verified | 420000 |
|
5AGXFA5H4F35C4G
IC FPGA 544 I/O 1152FBGA
|
Arria V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 190000 |
|
EP3CLS200F780C7
IC FPGA 413 I/O 780FBGA
|
Cyclone® III | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BGA | 780-FBGA (29x29) | Not Verified | 198464 |
|
1SG280HH3F55I1VG
IC FPGA 1160 I/O 2912BGA
|
Stratix® 10 GX | Tray | Active | 0.77V ~ 0.97V | Surface Mount | -40°C ~ 100°C (TJ) | 2912-BBGA, FCBGA | 2912-FBGA, FC (55x55) | Not Verified | 2800000 |
|
EP4CE30F23I7N
IC FPGA 328 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 28848 |
|
EP3SE260F1517I3
IC FPGA 976 I/O 1517FBGA
|
Stratix® III E | Tray | Obsolete | 0.86V ~ 1.15V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 255000 |
|
5AGXBA7D4F31C4G
IC FPGA 384 I/O 896FBGA
|
Arria V GX | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 896-BBGA, FCBGA | 896-FBGA (31x31) | Not Verified | 242000 |
