| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP4SE530H40C2N
IC FPGA 976 I/O 1517HBGA
|
STRATIX® IV E | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-HBGA (42.5x42.5) | Not Verified | 531200 |
|
10AX032H2F34I2LG
IC FPGA 384 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 320000 |
|
EP20K1000EFI672-2X
IC FPGA 508 I/O 672FBGA
|
APEX-20KE® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | -40°C ~ 100°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 38400 |
|
|
10AX057H1F34E1SG
IC FPGA 492 I/O 1152FCBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 570000 |
|
EP20K200EFI484-2X
IC FPGA 376 I/O 484FBGA
|
APEX-20KE® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | -40°C ~ 100°C (TJ) | 484-BBGA | 484-FBGA (23x23) | Not Verified | 8320 |
|
10AX048E4F29I3SG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA, FC (29x29) | Not Verified | 480000 |
|
|
10AX066H2F34I1SG
IC FPGA 492 I/O 1152FCBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 660000 |
|
|
10AX027H2F35I2SG
IC FPGA 384 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 270000 |
|
EP20K200EQC240-1X
IC FPGA 168 I/O 240QFP
|
APEX-20KE® | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 240-BFQFP | 240-PQFP (32x32) | Not Verified | 8320 |
|
EP2C15AF484A7N
IC FPGA 315 I/O 484FBGA
|
Cyclone® II | Tray | Active | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 125°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 14448 |
|
|
10AX066K4F35E3SG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 660000 |
|
|
10AX048H2F34I1HG
IC FPGA 492 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 480000 |
