| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP2S130F1508C4N
IC FPGA 1126 I/O 1508FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 1508-BBGA, FCBGA | 1508-FBGA, FC (40x40) | Not Verified | 132540 |
|
10AX048K2F35I2LG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 480000 |
|
EP2S130F1020C3NRB
IC FPGA 742 I/O 1020FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 132540 |
|
|
10AX057K2F35E2SG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 570000 |
|
EP2S90F780C4N
IC FPGA 534 I/O 780FBGA
|
Stratix® II | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA | 780-FBGA (29x29) | Not Verified | 90960 |
|
|
10AX027H1F34E1HG
IC FPGA 384 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 270000 |
|
5SGSMD8K3F40I3G
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Active | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
5SGSMD5K3F40C2LG
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 457000 |
|
5SGSMD6K2F40C2G
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Active | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 583000 |
|
5SGSMD8K3F40C4G
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
|
10AX048K2F35E1HG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 480000 |
|
|
10AX048K3F35I2LG
IC FPGA 396 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 480000 |
