| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SD110PJ3F43E3VGS1
IC FPGA 528 I/O 1760FBGA
|
Stratix® 10 DX | Tray | Obsolete | - | Surface Mount | 0°C ~ 100°C (TJ) | 1760-BBGA, FCBGA | 1760-FBGA (42.5x42.5) | Not Verified | 1325000 |
|
EP4SGX110FF35I3G
IC FPGA 372 I/O 1152FBGA
|
Stratix® IV GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 105600 |
|
EP3C16F256C8
IC FPGA 168 I/O 256FBGA
|
Cyclone® III | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 15408 |
|
5SGTMC7K2F40I2N
IC FPGA 600 I/O 1517FBGA
|
Stratix® V GT | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 622000 |
|
EP4CE55U19I7N
IC FPGA 324 I/O 484UBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 484-FBGA | 484-UBGA (19x19) | Not Verified | 55856 |
|
EP4SGX110HF35I3G
IC FPGA 488 I/O 1152FBGA
|
Stratix® IV GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 105600 |
|
EP3CLS150F780C7N
IC FPGA 413 I/O 780FBGA
|
Cyclone® III | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BGA | 780-FBGA (29x29) | Not Verified | 150848 |
|
EPF6024AQC240-2N
IC FPGA 199 I/O 240QFP
|
FLEX 6000 | Tray | Obsolete | 3V ~ 3.6V | Surface Mount | 0°C ~ 85°C (TJ) | 240-BFQFP | 240-PQFP (32x32) | Not Verified | 1960 |
|
EP4S40G2F40I2NAA
IC FPGA 654 I/O 1517FBGA
|
STRATIX® IV GT | Tray | Obsolete | 0.92V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 228000 |
|
EP4CE30F23C8N
IC FPGA 328 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 28848 |
|
EPF6024ATC144-2N
IC FPGA 117 I/O 144TQFP
|
FLEX 6000 | Tray | Obsolete | 3V ~ 3.6V | Surface Mount | 0°C ~ 85°C (TJ) | 144-LQFP | 144-TQFP (20x20) | Not Verified | 1960 |
|
EP4SGX70HF35C3
IC FPGA 488 I/O 1152FBGA
|
Stratix® IV GX | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 72600 |
