| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP4S40G2F40I1N
IC FPGA 654 I/O 1517FBGA
|
STRATIX® IV GT | Tray | Obsolete | 0.92V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 228000 |
|
EP1K30FC256-2
IC FPGA 171 I/O 256FBGA
|
ACEX-1K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 70°C (TA) | 256-BGA | 256-FBGA (17x17) | Not Verified | 1728 |
|
EP4S40G5H40I2NAD
IC FPGA 654 I/O 1517HBGA
|
STRATIX® IV GT | Tray | Obsolete | 0.92V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-HBGA (42.5x42.5) | Not Verified | 531200 |
|
EP1K50QC208-3AA
IC FPGA 147 I/O 208QFP
|
ACEX-1K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | 0°C ~ 70°C (TA) | 208-BFQFP | 208-PQFP (28x28) | Not Verified | 2880 |
|
EP1SGX10DF672C7N
IC FPGA 362 I/O 672FBGA
|
Stratix® GX | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 10570 |
|
EP1SGX25DF1020C6
IC FPGA 607 I/O 1020FBGA
|
Stratix® GX | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 25660 |
|
EPF10K10LC84-4
IC FPGA 59 I/O 84PLCC
|
FLEX-10K® | Tube | Obsolete | 4.75V ~ 5.25V | Surface Mount | 0°C ~ 70°C (TA) | 84-LCC (J-Lead) | 84-PLCC (29.31x29.31) | Not Verified | 576 |
|
EPF10K50VBC356-1
IC FPGA 274 I/O 356BGA
|
FLEX-10K® | Tray | Obsolete | 3V ~ 3.6V | Surface Mount | 0°C ~ 70°C (TA) | 356-LBGA | 356-BGA (35x35) | Not Verified | 2880 |
|
HC1S80F1020AXP
IC FPGA 782 I/O 1020FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 79040 |
|
HC1S60F1020BY
IC FPGA 782 I/O 1020FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 57120 |
|
5AGZME3H3F35C4N
IC FPGA 414 I/O 1152FBGA
|
Arria V GZ | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 360000 |
|
5AGZME5K3F40C4NCV
IC FPGA 674 I/O 1517FBGA
|
Arria V GZ | Tray | Obsolete | - | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 400000 |
