| Image | Mfr Part # | Series | Package | Product Status | Function | Type | Output Type | Number of Elements | Number of Bits per Element | Max Propagation Delay @ V, Max CL | Trigger Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
84000012A
DUAL J-K POSITIVE-EDGE-TRIGGERED
|
54ALS | Tube | Active | - | JK Type | Complementary | 2 | 1 | 21ns @ 5V, 50pF | Positive Edge |
|
|
M38510/37204B2A
OCTAL D-TYPE EDGE TRIGGERED FLIP
|
54ALS | Tube | Active | - | D-Type | Tri-State, Non-Inverted | 1 | 8 | 17ns @ 5V, 50pF | Positive Edge |
|
SN54HC374J
54HC374 OCTAL D-TYPE EDGE-TRIGGE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
JM38510/37201B2A
HEX D-TYPE FLIP-FLOPS WITH CLEAR
|
54ALS | Tube | Active | - | D-Type | Non-Inverted | 1 | 6 | 24ns @ 5V, 50pF | Positive Edge |
|
|
SNJ54ALS29821JT
10-BIT BUS INTERFACE FLIP-FLOPS
|
54ALS | Tube | Active | - | D-Type | Tri-State, Non-Inverted | 1 | 10 | 21ns @ 5V, 300pF | Positive Edge |
|
CY74FCT574ATSOCT
IC FF D-TYPE SNGL 8BIT 20SOIC
|
- | Bulk | Active | - | D-Type | Tri-State, Non-Inverted | 1 | 8 | 6.5ns @ 5V, 50pF | Positive Edge |
|
|
SNJ54ALS574BFK
OCTAL D-TYPE EDGE-TRIGGERED FLIP
|
54ALS | Tube | Active | - | D-Type | Tri-State, Non-Inverted | 1 | 8 | 22ns @ 5V, 50pF | Positive Edge |
|
CD54ACT109F3A
CD54ACT109 DUAL POSITIVE-EDGE TR
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
5962-9221804MRA
IC FF D-TYPE SNGL 8BIT 20CDIP
|
- | Tube | Obsolete | - | D-Type | Tri-State, Non-Inverted | 1 | 8 | 7.2ns @ 5V, 50pF | Positive Edge |
|
|
100351WRQMLV
100351 - D FLIP-FLOP, 100K SERIE
|
- | Bulk | Active | - | D-Type | Complementary | 1 | 6 | 2.2ns @ 5V, 3pF | Positive Edge |
|
84088012A
SN54HC112 DUAL J-K NEGATIVE-EDGE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
TLC59212IN
IC FF D-TYPE SNGL 8BIT 20DIP
|
- | Tube | Obsolete | - | D-Type | Inverted | 1 | 8 | 210ns @ 5V, 50pF | Positive Edge |
