| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1100Z-25
IC DELAY LINE 5TAP 25NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 5ns | 25ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1010S-175
IC DELAY LINE 10TAP 175NS 16SOIC
|
- | Tube | Obsolete | Nonprogrammable | 17.5ns | 175ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1004Z-5/T&R
IC DELAY LINE 5TAP 25NS 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 5ns | 25ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1100M-150
IC DELAY LINE 5TAP 150NS 8DIP
|
- | Tube | Obsolete | Nonprogrammable | 30ns | 150ns | 1 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1100LU-30/T&R
IC DELAY LINE 5TAP 30NS 8UMAX
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 6ns | 30ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1010S-60
IC DELAY LINE 10TAP 60NS 16SOIC
|
- | Tube | Obsolete | Nonprogrammable | 6ns | 60ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1135U-15
IC DELAY LINE 15NS 8UMAX
|
- | Tube | Obsolete | Multiple, NonProgrammable | 15ns | 15ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1110S-125
IC DELAY LINE 10TAP 125NS 16SOIC
|
- | Bag | Obsolete | Nonprogrammable | 12.5ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1013M-70
IC DELAY LINE 70NS 8DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 70ns | 70ns | 3 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1007S-1+
IC DELAY LINE PROG 16SOIC
|
- | Tube | Obsolete | Multiple, NonProgrammable | 3ns | 3ns ~ 10ns, 9ns ~ 40ns | 7 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LU-300
IC DELAY LINE 5TAP 300NS 8UMAX
|
- | Tube | Discontinued at | Nonprogrammable | 60ns | 300ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1013G-25
IC DELAY LINE 25NS 14DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 25ns | 25ns | 3 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
