| Image | Mfr Part # | Series | Package | Product Status | Type | Number of Circuits | Ratio - Input/Output | Differential - Input/Output | Input | Output | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
PL133-47SI
IC CLK BUFFER 1:4 150MHZ 8SOP
|
- | Tube | Active | Fanout Buffer (Distribution) | 1 | 1:4 | No/No | LVCMOS | LVCMOS | 2.25V ~ 3.63V |
|
ZL40292LDG1
IC CLK BUFFER 1:20 250MHZ 72QFN
|
- | Tray | Active | Fanout Buffer (Distribution) | 1 | 1:20 | Yes/Yes | Clock | HCSL | 3.135V ~ 3.465V |
|
SY89853UMG-TR
IC CLK MULTIPLX 2:1 2.5GHZ 32QFN
|
Precision Edge® | Tape & Reel (TR) | Active | Multiplexer | 2 | 2:1 | Yes/Yes | CML, LVDS, PECL | LVPECL | 2.375V ~ 3.6V |
|
SY89828LHY-TR
IC CLK BUFFER 2:10 1GHZ 64TQFP
|
Precision Edge® | Tape & Reel (TR) | Active | Fanout Buffer (Distribution), Multiplexer, Translator | 2 | 2:10 | Yes/Yes | LVDS, PECL | LVDS | 3V ~ 3.6V |
|
ZL40210LDG1
IC CLK BUFFER 2:8 750MHZ 32QFN
|
- | Tray | Active | Fanout Buffer (Distribution), Multiplexer | 1 | 2:8 | Yes/Yes | CML, HCSL, LVCMOS, LVDS, LVPECL | LVPECL | 2.375V ~ 3.465V |
|
SY100EL15LZI-TR
IC CLK BUFFER 2:4 16SOIC
|
100EL, Precision Edge® | Tape & Reel (TR) | Discontinued at | Fanout Buffer (Distribution), Multiplexer | 1 | 2:4 | Yes/Yes | ECL, PECL | ECL, PECL | 3V ~ 3.8V |
|
PL135-47OI-R
IC CLK BUFFER 1:4 40MHZ 16TSSOP
|
- | Tape & Reel (TR) | Discontinued at | Fanout Buffer (Distribution) | 1 | 1:4 | No/No | Crystal | LVCMOS | 1.62V ~ 3.63V |
|
SY100E111LJI-TR
IC CLK BUFFER 1:9 28PLCC
|
100E, Precision Edge® | Tape & Reel (TR) | Discontinued at | Fanout Buffer (Distribution) | 1 | 1:9 | Yes/Yes | PECL | PECL | 3V ~ 5.5V |
|
SY56216RMG-TR
IC CLK BUFFER 1:1 4.5GHZ 16MLF
|
Precision Edge® | Tape & Reel (TR) | Active | Buffer/Driver | 2 | 1:1 | Yes/Yes | CML, LVDS, LVPECL | CML | 2.375V ~ 2.625V |
|
SY100H641JZ-TR
IC CLK BUFFER 1:9 135MHZ 28PLCC
|
Precision Edge® | Tape & Reel (TR) | Obsolete | Fanout Buffer (Distribution) | 1 | 1:9 | Yes/Yes | PECL | TTL | 4.75V ~ 5.25V |
|
SY100EP14UK4I
IC CLK BUFFER 2:5 2GHZ 20TSSOP
|
100EP, Precision Edge®, ECL Pro® | Tube | Discontinued at | Fanout Buffer (Distribution), Multiplexer | 1 | 2:5 | Yes/Yes | HSTL, LVECL, LVPECL | LVECL, LVPECL | 2.37V ~ 5.5V |
|
SY100EP210UTG
IC CLK BUFFER 1:5 3GHZ 32TQFP
|
100EP, Precision Edge® | Tray | Active | Fanout Buffer (Distribution) | 2 | 1:5 | Yes/Yes | HSTL, LVECL, LVPECL | LVECL, LVPECL | 2.375V ~ 3.8V |
