| Image | Mfr Part # | Series | Package | Product Status | Output Isolation | Internal Switch(s) | Voltage - Breakdown | Topology | Voltage - Supply (Vcc/Vdd) | Duty Cycle | Frequency - Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
UCC3804DG4
IC OFFLINE SWITCH MULT TOP 8SOIC
|
- | Tube | Discontinued at | - | No | - | Boost, Buck, Flyback, Forward | 8.3V ~ 12V | 49% | Up to 1MHz |
|
UCC3807N-2G4
IC REG CTRLR PWM CM 8DIP
|
- | Bulk | Active | Isolated | No | - | Boost, Buck, Flyback, Forward | 8.3V ~ 13.5V | 78% | 1MHz |
|
UCC38083PWRG4
IC OFFLINE SW PUSH-PULL 8TSSOP
|
- | Tape & Reel (TR) | Obsolete | Isolated | No | - | Push-Pull | 8.3V ~ 15V | 49% | 50kHz ~ 1MHz |
|
UCC3810TD1
IC OFFLINE SWITCH DIE
|
- | Tube | Active | - | - | - | - | 8.3V ~ 11V | 50% | 1MHz |
|
UC2861N
IC OFFLINE SWITCH MULT TOP 16DIP
|
- | Tube | Obsolete | Non-Isolated | Yes | - | Full-Bridge, Half-Bridge, Push-Pull | 10.5V ~ 22V | - | 10kHz ~ 1MHz |
|
UCC3808N-1
IC OFFLINE SWITCH PUSH-PULL 8DIP
|
- | Bulk | Obsolete | Isolated | No | - | Push-Pull | 8.3V ~ 14V | 50% | 1MHz |
|
|
UCC3810N
IC OFFLINE SWITCH MULT TOP 16DIP
|
- | Bulk | Active | Isolated | No | - | Boost, Buck, Flyback, Forward | 8.3V ~ 11V | 49% | 1MHz |
|
UCC287501DBVR
CURRENT-MODE FLYBACK CONTROLLER
|
- | Tape & Reel (TR) | Active | Isolated | No | - | Flyback, Secondary Side SR | 10V ~ 26V | 80% | 65kHz |
|
|
UCC3808AN-1G4
IC OFFLINE SWITCH MULT TOP 8DIP
|
- | Tube | Obsolete | Isolated | - | - | Boost, Buck, Half-Bridge, Push-Pull | 8.3V ~ 15V | 49% | 1MHz |
|
UC3823BDW
IC OFFLINE SW MULT TOP 16SOIC
|
- | - | - | - | - | - | - | - | - | - |
|
|
UCC3809PW-1
IC OFFLINE SW MULT TOP 8TSSOP
|
- | Tube | Obsolete | Isolated | No | - | Boost, Buck, Flyback, Forward | 8V ~ 19V | 70% | 1MHz |
|
UC2848DWG4
IC OFFLINE SW MULT TOP 16SOIC
|
- | Tube | Obsolete | Isolated | No | - | Buck, Forward Converter | 10V ~ 22V | 79.5% | Up to 1MHz |
